PICO PicoScope 9402-05 Oscilloscopes (5Ghz, 500 MS/s, 2CH)
Number of input channels: 2
Analog bandwidth (–3 dB)[1]: Full: DC to 5 GHz
Middle: N/A
Narrow: DC to 450 MHz
Passband flatness: Full: ±1 dB to 3 GHz
Scale factors (sensitivity): 10 mV/div to 250 mV/div
Operating input voltage: ±800 mV
ADC resolution: 12 bits
Hardware vertical resolution: 0.4 mV/LSB without averaging
Overvoltage protection: ±1.4 V (DC + peak AC)
Input impedance: 50 Ω ±1.5 Ω (50 Ω ±1 Ω typical)
Input coupling: DC
Input connectors: SMA female
Timebase range: Real time sampling: 10 ns/div to 1000 s/div
Maximum sampling rate:
- Real time: 500 MS/s per channel simultaneously
- Random: Up to 1 TS/s or 1 ps trigger placement resolution
Record length
Real time sampling: From 50 S/ch to 250 kS/ch for one channel, to 125 kS/ch for two channels, to 50 kS/ch for three and four channels
Marker measurements: Absolute, Delta, Volt, Time, Frequency, Slope.
FFT mode
Dimensions: 160 × 55 × 220 mm (W × H × D) (W x H x D)
Net weight: 800 g
Temperature:
Operating, normal operation: +5 °C to +40 °C
Operating, for quoted accuracy: +15 °C to +25 °C
Storage: –20 °C to +50 °C
Humidity
Operating: Up to 85 %RH (non-condensing) at +25 °C.
Storage: Up to 95 %RH (non-condensing).
Altitude: Up to 2000 m
