PHYWE 15569-88 DEMO Advanced Physics Electricity/Electronics Building Block System

- Function and Applications:

Equipment set allowing the performance of 30 experiments about the following topics:

• Electric Circuits (9 experiments)

• Electrical Resistance (9 experiments)

• Electric Power and Work (1 experiment)

• Transformation of Energy (1 experiment)

• Electrochemistry (6 experiments)

• Safe Working with Electricity (2 experiments)

• Sensors (2 experiments)

- Benefits:

• Many experiments for qualitative and quantitative introduction to the topic electricity

• Circuit assemblies show their wiring diagram

• 100-percent compatibility between teacher and student building blocks

• Rugged magnetically adhesive puzzle-style building blocks with screen-printed electric symbols

• Building blocks are easy to remove and swap due to their gripper rims

• Safe electric contact is guaranteed by the use of a unique puzzle block system with corrosion-free gold plated contacts

• Teaching made easy thanks to the magnetic demonstration board

• Complete equipment set for quick and easy set-up and performance of the experiments

• Covers electric circuits, resistance, electric power and work, energy transformation, electrochemistry, sensors, safety issues

• The equipment is stored in a robust aluminum case with removable lid

• Foam insert for quick control if set content is complete

• Experiment guides for all experiments provided as PDF documents

• Compliant with international curricula

• Easy teaching and efficient learning through the digital experiment descriptions enclosed as QR codes

• Equipment and Technical Data:

• The equipment set consists of all necessary components for the experiments

• Robust storage case with foam insert fitting to the contained equipment

- Scope of delivery:

• Connector, straight, module DB: 09401-01, 6

• Connector, angled, module DB:09401-02, 6

• Connector, T-shaped, module DB: 09401-03, 4

• Connector interrupted, module DB: 09401-04, 4

• Junction, module DB: 09401-10, 2

• Connect.straight w.socket,mod. DB: 09401-11, 2

• Connector, angled with socket, module DB: 09401-12, 2

• Switch on/off, module DB: 09402-01, 2

• Switch, change-over, module DB: 09402-02, 2

• Socket for incandescent lamp E10 ,module DB: 09404-00, 3

• Resistor 1 Ohm,module DB: 09411-10, 1

• Resitor 10 Ohm,module DB: 09412-10, 1

• Resistor 50 Ohm,module DB: 09412-50, 1

• Resistor 100 Ohm,module DB: 09413-10, 2

• Resistor 10 kOhm,module DB: 09415-10, 1

• Resistor 47 kOhm,module DB: 09415-47, 1

• Potentiometer 250 Ohm, module DB: 09423-25, 1

• NTC-resistor,module DB: 09430-00, 1

• PTC-resistor, module DB: 09431-00, 1

• Support plate w. holder,module DB: 09471-00, 1

• Human model f.electric. safety,DB: 09480-00, 1

• Bell gong on 4-mm-plug: 05673-02, 1

• Battery holder module (C type), SB: 05605-00, 2

• Clamp on fixing magnet: 02151-01, 1

• Motor, 2 V DC: 11031-00, 1

• Disc for 11031-00: 11031-01, 1

• Conductors/non-conductors, l = 150 mm: 06107-50, 1

• Bimetal strip: 05913-00, 1

• Scale for demonstration board: 02153-00, 1

• Connecting plug, 2 pcs.: 07278-05, 1

• Electr.symbols f.demo-board,12pcs: 02154-03, 1

• Glass tank, 100x50x120 mm: 06620-10, 1

• Plate electrode holder: 06618-00, 2

• Metalelectrode, diverse metals | Element: Copper: 45212-00, 2

• Metalelectrode, diverse metals | Element: Zinc: 45214-00, 1

• Metalelectrode, diverse metals | Element: Lead: 45215-00, 2

• Metalelectrode, diverse metals | Element: Iron: 45216-00, 1

• Filament lamps 1.5V/0.15A,E10,10 pieces: 06150-03, 1

• Filament lamps 4V/0.04A, E10, 10: 06154-03, 1

• Filament lamp 6 V/3 W, E10, 10 pcs.: 35673-03, 1

• Filament lamps 12V/0.1A, E10, 10 pieces: 07505-03, 1

• Connecting cord, 32 A, 500 mm, red | Length: 100 mm: 07359-01, 1

• Connecting cord, 32 A, 500 mm, blue | Length: 100 mm: 07359-04, 1

• Connecting cord, 32 A, 500 mm, blue | Length: 500 mm: 07361-04, 2

• Connecting cord, 32 A, 500 mm, red | Length: 500 mm: 07361-01, 2

• Connecting cord, 32 A, 500 mm, blue | Length: 250 mm: 07360-04, 2

• Connecting cord, 32 A, 500 mm, red | Length: 250 mm: 07360-01, 2

- Necessary accessories:

• DEMO advanced Electricity necessary accessories: 15570-01

• PHYWE Demo Physics board with stand: 02150-00

- Recommended accessories:

• Moveable experimental table 90 x 75 cm, 30 mm table top withPP edge, with shelf for 3 boxes and socket board: 15500-00

• Handbuch Lehrerversuche Elektrik/Elektronik auf der Tafel, DEMO advanced Physik (ET), (in german): 01005-01
