PHOENIX CONTACT 3037481 ບລັອກຂໍ້ຕໍ່ຜ່ານ Feed Through Terminal Block STS 4 OG

Color: Orange

Width: 6.2 mm

Height: 43 mm, 50.5 mm

Length: 64.5 mm

Unit Weight: 10.014 g

Current Rating: 32 A

Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)

Number of Rows: 1 Row

Voltage Rating: 800 V

Wire Gauge Max: 10 AWG

Wire Gauge Min: 28 AWG

Wire Gauge Range: 28 AWG to 10 AWG

Connection Method: Spring Cage

Flammability Rating: UL 94 V-0

Number of Positions: 2 Position

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 60 C
