Flow range:
(0.03 ~ 16) ft/s
(0.01 ~ 5) m/s
Accuracy: ±1.0% of measured value.（0.5 m/s～5 m/s）
Repeatability: 0.2%.
Pipe Size: 1" ~ 32” (25mm～800mm)
Pipe Material: Carbon Steel、Stainless Steel、PVC
Measurement medium: Water
Function Specifications
Communication: RS485, Support MODBUS RTU, FUJI protocol.
Output
Analog output: 4 ~ 20 mA, ( max load 500 Ω ).
Pulse output: 0 ~ 9999 Hz, OCT ( min. and max. frequency is adjustable ).
TF card
Storage: 16GB (To prevail in kind)
Max: 1000 files
Interval: 1 ~ 60 seconds
Power Supply: 10.8V rechargeable Lithium Battery Power ( continuous operation of main battery 10 hours ).
Keypad: Tactile Keys
Display: 2.8" TFT black and white screen 240×320, with backlight LCD display.
Temperature
Transmitter: 14°F to 122°F (-10℃~ 50℃)
Transducer: 32°F to 176°F (0℃~ 80℃,standard )
Humidity: 0 ~ 99% RH, non-condensing.
Physical Specifications
Transmitter: NEMA13 ( IP54 ).
Transducer
Encapsulated design, IP68
Standard cable length: 5m
Weight
Transmitter: approximately 0.7kg
Transducer: (including transducer rail): 1.2kg
