Rated value | Polarity | Max for multiplex pin gauge | Min for single pin gauge | Max for single pin gauge
≤10A | 2 | 40 | 1.5 | 17
| 3 | 50 | 1.5 | 17
>10A~16A | 2 | 50 | 2 | 18
| 3 | 54 | 2 | 18
| >3 | 70 | 2 | 18
>16A~32A | 2 | 80 | 3 | 27
| 3 | 80 | 3 | 27
| >3 | 100 | 3 | 27
Maximum and minimum withdrawal force test apparatus is designed to meet the test requirements of IEC60884-1 clause 22 and figures 18/19 and VDE0620. It is to evaluate the maximum and minimum insertion and withdrawal of the plug from socket-outlet. The test apparatus consists of mounting plate, clamp, carrier, principal weight and supplementary weight. The apparatus is suitable for testing the socket-outlets with rated voltage not exceeding 250V and rated current less than 16A. The test plug and test pin gauge can be customized as per customers demands.
