PCE MWM 200 ເຊັນເຊີຄວາມຊຸ່ມຊື່ນຢ່າງແທ້ຈິງ

Specification

Mass fraction of water readability:0 ... 100 %

Moisture measurement range:±0.1 ... 100 % (Water mass fraction)

Maximum permissible absolute error moisture measurement:Varies by material, lab test required

Temperature measurement range:+5 ... +80 °C

Maximum permissible absolute error temperature measurement:±1 °C

Outputs:RS 485 Modbus RTU / 4-20 mA

Power supply:24 V / 18-36 V

Input power:200 mA

Sensor dimensional:335 x 80 x 80 mm

Sensor weight:8 kg

Inputs:2 x digital 24 VDC

Operating temperature range:

- Normal industrial plant-20 ... +120 °C

- With extended temperature protection-20 ... +145 °C

- Ambient temperature electronics unit-20 ... +80 °C

Dimensions electronics unit:255 x 170 x 60 mm

Mass of the electronics unit:2 kg

Life span (approx.):10 years
