Resistance
Measurement range up to: 0 ... 60000 µΩ
Resolution: 1 µΩ
Accuracy: ±0.25 % of Rd +25 digits (@ 23 ±5 °C)
Resistance
Measurement range up to: 60000 µΩ ... 600 mΩ
Resolution: 10 µΩ
Accuracy: ±0.25 % of Rd +25 digits (@ 23 ±5 °C)
Resistance
Measurement range up to: 600 ... 6000 mΩ
Resolution: 100 µΩ
Accuracy: ±0.25 % of Rd +25 digits (@ 23 ±5 °C)
Resistance
Measurement range up to: 6000 ... 60000 mΩ
Resolution: 1000 µΩ
Accuracy: ±0.25 % of Rd +25 digits (@ 23 ±5 °C)
Resistance
Measurement range up to: 60000 mΩ ... 600 Ω
Resolution: 10 mΩ
Accuracy: ±0.25 % of Rd +25 digits (@ 23 ±5 °C)
Resistance
Measurement range up to: 600 ... 6000 Ω
Resolution: 100 mΩ
Accuracy: ±0.75 % of Rd +3 digits (@ 23 ±5 °C)
General technical data
Measuring functions: HOLD
Display type: LCD with backlight
Display size: 3.3 Inch
Interface: RS232
Standard(s): EN 61010-1, EN 61325-1
Measuring method: 4-wire method for mΩ measurement
Test current: 10 A: 60000 µΩ
1 A: 600 mΩ
100 mA: 6000 mΩ
10 mA: 60000 mΩ
1 mA: 600 Ω
100 µA: 6000 Ω
Fuse(s): 10 A / 250 V
Menu language: English, English (GB)
Protection class (device): IP30
Power supply: 100 ... 240 V AC | 47/63 Hz
Connector type: Schuko plug
(Rechargeable) battery: 8 x 1.5 V AA battery , Zinc carbon
Capacity: 1200 mAh
Operating conditions: 0 ... 50 °C , 0 ... 80 % RH
Storage conditions: 0 ... 50 °C , 0 ... 80 % RH
Dimensions ( L x W x H ): 220 x 125 x 64 mm
Weight: 777 g
