PCE LMD 10 ເຄື່ອງວັດແທກພາບ (400,000 Lux)

Measuring range:

1000 ... 400,000 Lux

0.0 ... 999.9 Lux

Resolution:

1 Lux

0.1 Lux

Measuring range (footcandle):

1000 ... 400,000 fc

100 ... 999 fc

0.00 ... 99.00 fc

Resolution:

1 fc

1 fc

0.01 fc

Accuracy:

±5 % of measured value ±10 digits with standard light A

±10 % of measured value ±10 digits

Repeatability: ±2 %

Sampling rate: 4 Hz

Sampling rate peak hold: 10 µs

Sensor: silicon photodiode with spectral filter

Interface: Micro-USB

Data storage: 32,000 measurement sets

Power supply battery: 3.7 V Li-Ion battery

Power supply USB: 5 V DC, 1 A

Operating conditions: -10 … 50 °C / 14 ... 122°F / <80 % RH, non-condensing

Storage conditions: -20 … 50 °C / -4 ... 122° / <80 % RH, non-condensing

Dimensions:

Meter: 162 x 88 x 32 mm / 6.4 x 3.5 x 1.3"

Sensor: 102 x 60 x 25 mm / 4 x 2.4 x 1"

Weight: ca. 320 g / 11.3 oz

Delivery Scope

1 x Photometer PCE-LMD 10

1 x USB Cable

1 x PC software

1 x Service bag

1 x Instruction Manual
