- Rated Power (VA): 4500
- Output Form: 1Ø/2Ø; 3Ø
- Output Voltage Max (1Ø/2Ø; 3Ø) (l-n/l-l):
Direct: 135/270; 135/234
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1):
1Ø/2Ø 202/404; 270/540; 338/600
3Ø 202/350; 270/468; 338/585
- Current (1Ø/2Ø; 3Ø) (Arms):
Direct: 36/12; 12/Ø
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1):
1Ø/2Ø 24/8; 18/6; 14.4/4.8
3Ø 8/Ø; 6/Ø; 4.8/Ø
- Frequency Range:
Direct: 20~5000
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 45~5000; 45~5000; 45~5000
- Input Power: 3Ø 47-63Hz
- Unit Height (In/mm/U):
345AMX: 14/356/8U
Transformer Module: 5.25/133/3U
- Unit Weight (Lbs/Kg):
345AMX: 190 /86.3
Transformer Module: 125 /56.8
- Output Frequency:
20~5,000 Hz Direct Coupled
45~5,000 Hz Transformer Coupled
- Line Regulation: 0.1% max for a ±10% line change
- Load Regulation:
Direct Coupled Ranges:
0.25% 20 to 2,000 Hz.
0.50% 2,000 to 5,000 Hz.
- Output Distortion:
0.1% THDAVG 45 ~ 1,000 Hz
0.25% THDAVG 20 ~ 5,000 Hz
- Ripple and Noise: -72dB
- Response Time: 5 μsec typ
