- Rated Power (VA): 500
- Output Form: 1Ø/2Ø
- Output Voltage Max (l-n/l-l):
Direct: 135/270
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 202/404; 270/540; 338/600
- Output Current (Arms):
Direct: 4/2
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 2.6/1.3; 2/1; 1.6/0.8
- Frequency Range:
Direct: 20~5000
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 45~5000; 45~5000; 45~5000
- Input Power: 1Ø 47-63Hz
- Unit Height (In/mm/U): 5.25/133/3U
- Unit Weight (Lbs/Kg): 97/44
- Output Frequency Line Regulation: 0.1% max for a ±10% line change
- Load Regulation: Direct Coupled Ranges:
0.25% 20 to 2,000 Hz.
0.50% 2,000 to 5,000 Hz.
Improves to less than 0.05% with external sense and CSC enabled.
-Output Distortion
0.1% THDAVG 45 to 1,000 Hz
0.25% THDAVG 20 to 5,000 Hz
-Ripple and Noise: -72dB
- Response Time: 5 µsec typ. For step load change.
Small signal bandwidth = 5 Hz to 50 KHz
