OWON SPM3051 ການສະຫນອງພະລັງງານ DC ແລະ Multimeter (1CH; 150W; 0-30V; 5A)
Channel: Single Channel Output
Total Output Power: 150W
Channel Output: 0 - 30V / 0 - 5A
Display: 2.8 inch color LCD display
Interface: USB Device, USB Host (5V1A)
Dimension(W x H x D): 82 x 142 x 226 (mm)
Working Temperature: 0 - 40℃
Weight: Approx. 1.5kg
DC Power Specifications:
Rated Output (0℃-40℃): Voltage: 0 - 30V; Current: 5A; Output Power : 150W
Load Regulation: Voltage: ≤30mV; Current: ≤20mA
Power Regulation: Voltage: ≤30mV; Current: ≤20mA
Setting Resolution: Voltage: 10mV; Current: 1mA
Readback Resolution: Voltage: 10mV; Current: 1mA
Value Resolution (within 12 months) (25℃±5℃): Voltage: ≤0.1% ± 20mV; Current: ≤0.05% ± 10mA
Readback Value Resolution (25℃±5℃): Voltage: ≤0.1% ± 20mV; Current: ≤0.1% ± 10mA
Ripple/Noise(*): Voltage(Vp-p): ≤30mVp-p; Voltage (rms): ≤3mVrms; Current (rms): ≤30mAp-p
Output temperature coefficient (0℃-40℃): Voltage: 100ppm/℃; Current: 200ppm/℃
Readback temperature coefficient: Voltage: 100ppm/℃; Current: 200ppm/℃
Response Time(50%-100% rated load): ≤1.0ms
Storage: 4 groups of data
Multimeter Specifications:
Full Scale Reading: 4½ digits
Auto Range: √
Measure: Voltage, Current, Capacitance, Resistance, Continue，Diode(0-2V) test
Capacitance: 20.000nF,200.00nF,2.0000uF,20.000uF,200.00uF, 2.0000mF: ±(3.0%±10digit)
Voltage: DCV: 200.00mV: ±(0.3%±10digit), 2.0000V, 20.000V, 200.00V,1000V: ±(0.3%±5digit), ACV: 200.00mV, 2.0000V, 20.000V, 200.00V: ±(0.8%±10digit) 750V: ±(1%±10digit)
Current: DCA: 200.00mA:±(0.8%±10digit),10.000A: ±(2.5%±10digit); ACA: 200.00mA:±(1%±10digit),10.000A: ±(2.8%±10digit)
Impedance: 200.00Ω,2.0000kΩ,20.000kΩ,200.00kΩ,2.0000MΩ: ±(0.8%±10digit),20.000MΩ: ±(1%±3digit); 100MΩ: ±(5%±10digit)
