Output voltage: 0-80V
Output current: 10A
Max output power: 500W
OVP: 85V
OCP: 11A
OTP: 85℃
Load Regulation: ≤20mV(voltage)/ ≤10mA(current)
Power Resolution: ≤20mV(voltage)/ ≤10mA(current)
Setting Resolution: 10mV/ 1mA
Readback Resolution: 10mV/ 1mA
Setting accuracy (25℃±5℃): ≤0.1% + 20mV(voltage)/ ≤0.05% + 10mA(current)
Readback accuracy (25℃±5℃): ≤0.1% + 20mV(voltage)/ ≤0.05% + 10mA(current)
Ripple/Noise (20Hz-20MHz: ≤50mVp-p; ≤15mAp-p
Output Temperature Coefficient (0℃-40℃): 100ppm/℃ / 200ppm/℃
Readback Temperature Coefficient: 100ppm/℃ / 200ppm/℃
Response Time (50%-100% rated load): ≤5.0ms
Storage: 4 groups of data
Display: 2.8inch LCD (IPS)
Dimension: 82mm(W)x142mm(H)x226mm(D)
Weight: Approx. 1.8kg
Accessories: Power supply main device, Power Cord, Quick Guide, USB Cable
