Bandwidth 200MHz
Sample Rate 1Gs/s
Channel 2 + 1 (external)
Record Length max 10M I
nput Coupling DC, AC, and GND
Input Impedance 1MΩ ± 2%, in parallel with 10pF ± 5pF
Channel Isolation 50MHz : 100 : 1, 10MHz : 40 : 1
Max Input Voltage 400V (PK - PK) (DC + AC, PK - PK)
DC Gain Accuracy ±3%
DC Accuracy average≥16 : ±(3% reading + 0.05 div) for △V
Probe Attenuation Factor 1X, 10X, 100X, 1000X
LF Respond (AC, -3dB) ≥10Hz (at input, AC coupling, -3dB)
Sampling Rate / Relay Time Accuracy ±100ppm
Interpolation sin (x) / x Interval (△T)
Accuracy (full bandwidth) Single：±(1 interval time + 100ppm × reading + 0.6ns); Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns)
Vertical Resolution (A/D) 8 bits resolution (2 channels simultaneously)
Vertical Sensitivity 2mV/div~10V/div
Trigger Type Edge, Pulse, Video, Slope, Alternate
Trigger Mode Auto, Normal, Single
Trigger Level ±6 divisions from screen center
Acquisition modes Sample, Peak Detect, and Average
Line / Field Frequency (video) NTSC, PAL and SECAM standard
Cursor Measurement △V, and △T between cursors
Automatic Measurement Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot,
Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty Waveform Math ＋, －, ×, ÷, FFT
Waveform Storage 15 waveforms Lissajous
Figure Bandwidth full bandwidth Phase Difference ±3 degrees Communication
Interface USB, USB flash disk storage, Pass / Fail, LAN, VGA
Cymometer available Power Supply 100V - 240V AC, 50/60Hz, CAT Ⅱ Power
Consumption < 24W Fuse 2A, T class, 250V Battery (optional) 7.4V, 8000mA
Dimension (W × H × D) 340 × 155 × 70 (mm)
Weight: 1.8Kg
