Bandwidth:100MHz
Sample Rate:1GS/s
Horizontal Scale (s/div): 2ns/div～100s/div, step by 1~2~5
Channel:2+1 (external)
Display: 8”color LCD, 800 x 600 pixels
Record Length: 1M (optional 10M)
Vertical Resolution (A/D):8 bits (2 channels simultaneously)
Vertical Sensitivity:2mV/div～10V/div (at input)
Trigger Type:Edge, Pulse, Video, Slope, and Alternate
Trigger Mode:Auto, Normal, and Single
Waveform Math:＋, －, ×, ÷, invert, FFT
Communication Interface: USB host, USB device, Pass / Fail, LAN, VGA (optional)
Battery: not supported
Dimension (W × H × D): 348 × 170 × 78 (mm)
Weight (without package): 1.50 kg
Accessories: Power Cord, CD Rom, Manual, USB Cable, Probe, Probe Adjustment, Soft Bag
