Model		SDS5032E	SDS6062E	SDS7072E	SDS7102E	SDS7122E
Bandwidth		30MHz	60MHz	70MHz	100MHz	125MHz
Sample Rate (real time)		250MS/s	500MS/s	1GS/s
Horizontal Scale (s/div)		4ns/div～100s/div, step by 1~2~4	5ns/div - 100s/div, step by 1 - 2 - 5	2ns/div - 100s/div, step by 1 - 2 - 5
Rise Time (at input, typical)		≤11ns
Channel		2 + 1 (external)
Display		8" color LCD, TFT display , 800 × 600 pixels, 65535 colors
Input Impedance		1MΩ ± 2%, in parallel with 15pF±5pF
Channel Isolation		50Hz : 100 : 1, 10MHz : 40 : 1
Max Input Voltage		400V (PK - PK) (DC+AC, PK - PK)
DC Gain Accuracy		±3%
Record Length		10K	100K (optional 10M)
DC Accuracy (average)		Average≥16：±(3% reading + 0.05 div) for △V
Probe Attenuation Factor		1X, 10X, 100X, 1000X
LF Respond (AC, -3dB)		≥5Hz (at input, AC coupling, -3dB)
Sample Rate / Relay Time Accuracy		±100ppm
Interpolation		sin (x) / x
Interval (△T) Accuracy (full bandwidth)		Single : ±(1 interval time + 100ppm × reading + 0.6ns), Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns)
Input Coupling		DC, AC , and GND
Vertical Resolution (A/D)		8 bits resolution (2 Channels simultaneously)
Vertical Sensitivity		5mV/div～10V/div (at input)	2mV/div～10V/div (at input)
Trigger Type		Edge, Pulse, Video, Slope	Edge, Pulse, Video, Slope, Alternate
Trigger Mode		Auto, Normal, Single
Trigger Level		±6 divisions from screen center
Line / Field Frequency (video)		NTSC, PAL, and SECAM standard
Cursor Measurement		△V, and △T between cursors
Automatic Measurement		Vpp, Vavg, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot, Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty
Waveform Math		＋, －, ×, ÷, FFT
Waveform Storage		15 waveforms
Lissajous Figure	Bandwidth	Full bandwidth
	Phase Difference	±3 degrees
Communication Interface		USB, USB flash disk storage, Pass / Fail, LAN, VGA (optional）
Cymometer		available
Power Supply		100V - 240V AC, 50/60Hz, CAT Ⅱ
Power Consumption		＜18W
Fuse		2A, T class, 250V
Battery		not supported
Dimension (W×H×D)		348 × 170 × 78 (mm)
Weight (without package)		1.50 kg

OWON SDS6062E oscilloscope ດິຈິຕອນ (60Mhz, 500MSa/s, 2 CH)
