Rated Output (0°C-40°C):
Voltage: 0-80V
Current: 0-20A
Power: 4*500W
Power Supply: 198V-240Vac; 45Hz-65Hz
Load Regulation±(% of Output+Offset):
CV: ≤0.05% + 20mV
CC: ≤0.1% + 30mA
linear Regulation±(% of Output+Offset):
CV: ≤0.05% + 20mV
CC: ≤0.1% + 30mA
Settings Resolution: 10mV/1mA
Readback Resolution: 10mV/1mA
Settings Accuracy:
Voltage: ≤0.05% ± 20mV
Current: ≤0.1% ± 30mA
Readback Accuracy:
Voltage: ≤0.05% ± 20mV
Current: ≤0.1% ± 30mA
Noise/Ripple(*):
Voltage: ≤50mVp-p
Current: ≤30mArms
Temperature Coefficient (0°C-40°C): 100ppm/°C (Voltage); 200ppm/°C (Current)
Readback Temperature Coefficient: 100ppm/°C (Voltage); 200ppm/°C (Current)
Recovery Time (10%~90% rated load): ≤5.0ms
Operation Temperature: 0-40°C
Interface: USB ,LAN,RS485,RS232
Display: 4.3 inch TFT LCD Screen
Size (W*H*D mm): 215x133x446.2
Weight (kg): ~6
