Fall Time: 6 ns
Rise Time: 24 ns
Technology: Si
Unit Weight: 187 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Qg - Gate Charge: 10 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 37 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 9.5 ns
Typical Turn-Off Delay Time: 19 ns
Id - Continuous Drain Current: 49 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 29 S
Rds On - Drain-Source Resistance: 8.1 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
