Width: 3.05 mm
Height: 0.75 mm
Length: 3.05 mm
Fall Time: 4.5 ns
Rise Time: 22 ns
Technology: Si
Unit Weight: 29.500 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 15 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 4.1 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 12 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 57 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 53 S
Rds On - Drain-Source Resistance: 8.8 Ohms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.5 V
