Width: 2 mm
Height: 0.75 mm
Length: 2 mm
Fall Time: 27 ns
Rise Time: 27 ns
Technology: Si
Unit Weight: 9 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 15 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.9 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 8 ns
Typical Turn-Off Delay Time: 74 ns
Id - Continuous Drain Current: 5.9 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 25 mOhms
Vds - Drain-Source Breakdown Voltage: 12 V
Vgs th - Gate-Source Threshold Voltage: 800 mV
