Width: 0.85 mm
Height: 0.7 mm
Length: 1.6 mm
Fall Time: 7.6 ns
Rise Time: 4.4 ns
Technology: Si
Unit Weight: 30 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 1.82 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 300 mW
Vgs - Gate-Source Voltage: - 6 V, + 6 V
Typical Turn-On Delay Time: 3.7 ns
Typical Turn-Off Delay Time: 25 ns
Id - Continuous Drain Current: 915 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1.4 S
Rds On - Drain-Source Resistance: 230 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 450 mV
