OMEGA XBPT35PE ບລອກຕ່າງດິນຕຳແໜ່ງກະເປົາສະຫນາມສະຫນາມ, ຕ້ານການສະເໜີສະຫນາມ (14 to 2 AWG)

Wire Gauge: 14 to 2 AWG

Cover Width: 2.2 mm

Amperage, Max: 0 A

Color Options: Green/Yellow

Terminal Width: 16 mm

Voltage Rating: N/A

Wire Size, Max: 35 mm²

Load Current, Max: 65 A

Cross-Section Area: 35 mm²

V/A/AWG Compliance: Amperage, Max (IEC 60 947-7-1)=125 A;Wire Gauge (IEC 60 947-7-1)=14 to 2 AWG;Wire Gauge (UL-cUL Ratings)=14 to 2 AWG;Wire Gauge (EN 50 AWG 0 AWG191)=14 to 2 AWG

Contamination Class: 3

Number of Terminals: 2

Rated Surge Voltage: 8 kV

Additional Features 1: Grounding terminal block

Compatible Wiring Note: Stranded Ferrule with Plastic Sleeve=0.25 - 10 mm²;Stranded with Ferrule=None;Stranded with Ferrule without Plastic Sleeve=0.25 - 6 mm²;Stranded with Twin Ferrule with Plastic Sleeve=1.5 - 2.5 mm²

Insulation Strip Length: 25 mm
