Display: No Display
Accuracy: ± 0.02 %
Features: Blade Angle : 30° ; Bearing Styles : Self-lubricating, ceramic hybrid ball bearings
Approvals: RoHS, CKCA, CE
Linearity: ±1%
Materials: Aluminum
Output Detail: Analog Output: 4 to 20 mA, 1 to 5V, 24 mA overflow condition (dip switch selectable);Signal Level:10 mV rms to 30 Vdc;Load Resistance Note:Maximum 650 Ω @ 24 Vdc;Recommended Minimum Load Resistance: 50 KΩ;Pulse Scaling:Divide by 1,10,100 per flow unit of measure
Output Signal: Current, Voltage, DC Pulse
Overload, Max: 30 ACFM
Repeatability: ±0.25%
Data Interface: RS232
Flow Rate Note: Air 35 to 40 psi @ 0.25lb/ft³,Natural Gas 2 to 3 psi @ 0.05lb/ft³
Humidity Range: 0 to 90% RH non-condensing
Pipe Size, Max: 1 in
Supply Voltage: 13 to 30 Vdc
Electrical Output: Amplified Square Wave
Materials, Wetted: 17-4 Stainless Steel, 316L Stainless Steel
Supply Power Note: 13 to 30 Vdc Standard, 100 to 240 Vac (-AC) (optional), Reverse Polarity Protection
Temperature Drift: 40 ppm/°C
Pressure Drop Note: 1 psid @ Air, 0.2 psid @ Natural Gas
Pressure Drop, Max: 1 psi
Repeatability Note: ±0.25% over tabulated repeatable range
Media Compatibility: Air, Natural Gas
Input Control Signal: MCP Pickup
Frequency Input Range: 0.2 to 4000 Hz
Operating Pressure, Max: 3850 psi
Process Connection Size: 1 in
Process Connection Type: NPT Male
Volumetric Flow Rate, Max: 20 ACFM
Volumetric Flow Rate, Min: 0.72 ACFM
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
