Accuracy: ± 2 %
Output Detail: current
Pressure Type: Gauge
Supply Current: 50 mA max
Supply Voltage: 12 to 18 Vdc
Viscosity Range: 5 cPs
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 4
Materials, Wetted: FKM, Polypropylene, PVC
Supply Power Note: 12 to 18 Vdc @ 50 mA maximum
Pressure Drop Note: max pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a max temperature of 93°C (200°F) at 18 psig maximum
Pressure Drop, Max: 1.1 psi
Repeatability Error: ±1%
Loop Resistance, Max: Ω = (V supply–12V)/0.02 A
Temperature Accuracy: ± 1.7 °C
Center-to-Center Length: 75 in
Operating Pressure Note: Do not exceed maximum ratings of the piping. Depending on the material of the fitting, the operating temperature/pressure may be limited by the piping and not by the sensor. For all PVC tee fittings, do not exceed 150 psig @ 27°C (80°F), 100 psig @ 38°C (100°F), 60 psig @ 49°C (120°F) or 30 psig @ 60°C (140°F), owing to thesert the tee. FP7000 sensor: 0 to 26°C (32 to 80°F) up to 150 psig; max pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a max temperature of 93°C (200°F) at 18 psig maximum
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 3 in
Process Connection Type: NPT Female
Process Temperature, Max: 93 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 460 GPM
Volumetric Flow Rate, Min: 25 GPM
Operating Temperature, Max: 100 °C
Operating Temperature, Min: 0 °C
Material Construction Option: PVC Fittings
