Mounting: Any (preferably with solenoid system upright)
Cv Factor: 0.22 gal/min
Materials: Brass, FKM, Stainless Steel 300, Stainless Steel 400, Copper
Coil Power: 8 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Direct Acting
Cycling Rate: 1000 cpm
Orifice Size: 3/32 in
Supply Voltage: 120 Vac
Valve Position: Normally Open
Enclosure Ratings: NEMA Type 4
Materials, Wetted: Brass, Copper, FKM, Stainless Steel
Voltage Tolerance: ±10%
Open Response Time: 8 to 15 ms
Close Response Time: 8 to 15 ms
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Exhaust Orifice Size: 3/32 in
Coil Molding Material: Black Polyester (Class F): SV8COIL-115AC, SV8COIL-24AC/60HZ, SV8COIL-220AC Black Polyamide (Class F): SV8COIL-12DC, SV8COIL-24DC Black Polyphenylensulphide (Class H): SV8COIL-115/60HZ
Operating Pressure Note: AC 60 psi, DC 60 psi
Operating Pressure, Max: 60 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: BSPP Male
Process Temperature, Max: 137 °C
Process Temperature, Min: -10 °C
