Mounting: Any (preferably with solenoid system upright)
Cv Factor: 0.28 gal/min
Materials: Brass, FKM, Stainless Steel 300, Stainless Steel 400, Copper
Coil Power: 8 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Direct Acting
Cycling Rate: 1000 cpm
Orifice Size: 1/8 in
Valve Position: Normally Open
Enclosure Ratings: NEMA Type 4
Materials, Wetted: Brass, Copper, FKM, Stainless Steel
Voltage Tolerance: ±10%
Open Response Time: 10 to 20 ms
Close Response Time: 20 to 30 ms
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Coil Molding Material: Black Polyester (Class F): SV8COIL-115AC, SV8COIL-24DC/60HZ, SVCOIL-24AC/50 to 60HZ, SV8COIL-220AC Black Polyamide (Class F): SV8COIL-12DC, SV8COIL-24DC, all 12 W coils Black Polyphenylensulphide (Class H): SV8COIL-115/60HZ Black Epoxy Resin (Class H): All 14 W coils
Operating Pressure Note: AC 145 psi, DC 85 psi
Operating Pressure, Max: 145 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: BSPP Male
Process Temperature, Max: 137 °C
Process Temperature, Min: -10 °C
