Mounting: Pipe mounting, any direction
Cv Factor: 0.35 gal/min
Materials: Aluminum, Nitrile Rubber
Coil Power: 10 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Pilot Operated
Orifice Size: 5/32 in
Supply Voltage: 120 Vac
Valve Position: Normally Closed
Static Pressure: 5 times max psid
Enclosure Ratings: IP65, NEMA Type 4
Materials, Wetted: Aluminum, Buna-N (NBR), Copper, Delrin, Stainless Steel
Supply Power Note: 10 W, 120 Vac coils, 50 to 60 Hz
Open Response Time: 10 to 30 ms
Close Response Time: 10 to 30 ms
Media Compatibility: Air
Additional Features 1: Slow Closing
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 15 psi
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Process Temperature, Max: 74 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: -9 °C
