Accuracy: ± 0.25 %
Accuracy Note: 0.25% linearity, hysteresis and repeatability combined
Output Signal: Millivolt
Pressure Type: Gauge
Pressure, Max: 40 bar
Pressure, Min: 0 bar
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 10 Vdc
Input Resistance: 350 Ω
Electrical Output: 3 mV/V
Materials, Wetted: 17-4 Stainless Steel
Output Resistance: 315 Ω to 530 Ω
Supply Power Note: 10 Vdc (15 V maximum)
Zero/Balance Error: ± 2.0% FSO
Burst Pressure Note: 300% of rated pressure
Electrical Connection: MIL-26482-I 10-6P
Electrical Output Note: 3 mV/V nominal
Process Connection Size: 1/4 in
Process Connection Type: BSPP Female
Operating Temperature, Max: 149 °C
Operating Temperature, Min: -73 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Thermal Effect on Span error, Max: 0.0054% rdg/°C
Thermal Effect on Zero error, Max: 0.0054% rdg/°C, 0.008% FSO/°C
