Weight: 725 g
Accuracy: ± 0.2 %
Stability: ± 0.5%
Vibration: 0.1% upper limit for 3 g @ 200 Hz
Fill Fluid: DC 200 silicone oil
Accuracy Note: ± 0.2% of calibrated span including linearity, hysteresis and repeatability
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 5000 psi
Pressure, Min: 0 psi
Response Time: 20 ms
Accuracy Class: 0.1% to 0.25%
Stability Note: ± 0.5% of upper range for 6 months
Supply Voltage: 12 to 40 Vdc
Electrical Output: 4 to 20 mA
Materials, Wetted: 316 Stainless Steel
Supply Power Note: 12 to 40 Vdc with reverse polarity protection
Enclosure Material: 316 Stainless Steel
Loop Resistance, Max: (Vs – 12) x 50
Additional Features 1: Connection Transmitter
Additional Features 2: Cast Head: CF-8M (316 cast SS) with Buna-N O-ring
Electrical Connection: 1/2 NPT male Conduit with Cable
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Storage Temperature, Max: 100 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 100 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 82 °C
Compensated Temperature, Min: -29 °C
Thermal Effect on Span error, Max: ± 0.02% FS/°F, ± 0.032% FS/°F
Thermal Effect on Zero error, Max: ± 0.02% FS/°F, ± 0.032% FS/°F, ± 0.02% FS/°F, ± 0.032% FS/°F
