Weight: 374 g
Accuracy: ± 0.3 %
Vibration: ± 0.1% FS for 3 g to 200 Hz
Fill Fluid: DC 200 silicone oil
Accuracy Note: ± 0.3% of span @ 25°C (includes linearity, hysteresis and repeatability)
Output Signal: Current
Pressure Type: Vacuum
Pressure, Max: -30 inHg
Pressure, Min: 0 psi
Accuracy Class: > 0.25%
Proof Pressure: 3x Full Scale
Supply Voltage: 12 to 30 Vdc
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: 316 Stainless Steel, 316L Stainless Steel
Relative Humidity: 0 to 1
Zero/Balance Error: 4 mA ± 2%
Proof Pressure Note: 300% of rated pressure
Loop Resistance, Max: 900 Ω @ 30 Vdc
Electrical Connection: 1/2 NPT male Conduit with Cable
Electrical Output Note: 4 to 20 mA(2 wire)
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Storage Temperature, Max: 100 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -40 °C
Span Setting Adjustable Range: 16 mA ± 1% of span
Thermal Effect on Span error, Max: ± 2%
Thermal Effect on Zero error, Max: ± 2%, ± 2%
