Accuracy: ± 0.05 %
Diameter: 1.5 in
Cable Length: 15 m
Accuracy Note: 0.5% linearity, hysteresis, and repeatability combined
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 10 psig
Pressure, Min: 0 psig
Accuracy Class: > 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 10 to 40 Vdc
Electrical Output: 4 to 20 mA
Materials, Wetted: 17-4 Stainless Steel, 316 Stainless Steel
Zero/Balance Error: 4 mA ± 0.5%
Burst Pressure Note: 300% of rated pressure
Loop Resistance, Max: (Input voltage – 10) x 50
Electrical Connection: Submersible Cable
Electrical Output Note: 4 to 20 mA ± 10% adj
Process Connection Note: Nose protector included
Process Connection Type: Submersible
Thermal Effect on Span error, Max: 0.0054% rdg/°C
Thermal Effect on Zero error, Max: 0.0054% rdg/°C, 0.009% FSO/°C
