Shock: 50 g, 11 ms, half-sine horizontal and vertical axis
Weight: 285 g
Accuracy: ± 0.2 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: ± 20 g
Compliance: RoHS
Applications: Building and Maintenance, Fluid Measurement and Control, Waste Management
Accuracy Note: (Combined Linearity, Hysteresis and Repeatability): Standard ± 0.20% BSL or high accuracy, option “HH”, ± 0.08% BSL Setting Accuracy(Span/Zero): ± 0.5% full scale typical, ± 1.0% full scale maximum (± 1.0% full scale typical, ± 2.0% full scale maximum for ranges ≤ 2.5 psi)
Cable Sealing: Fused to case via molded Neoprene boot rated to 610 m (2000') depth
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 15 psi
Pressure, Min: 0 psi
Response Time: 500 µs
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 4x Full Scale
Cable Material: ETFE
Proof Pressure: Up to 3000 psi
Stability Note: Long Term Stability (1 year.): ± 0.1% full scale typical
Supply Voltage: 10 to 30 Vdc
Pressure Cycles: 1 million
Electrical Output: 4 to 20 mA
Materials, Wetted: 316 Stainless Steel
Supply Power Note: 10 to 30 Vdc [(10 to 20 Vdc above 105°C (229°F)] maximum loop res Ω = (Vs-10) x 50
Response Time Note: 500 usec, 0 to 90% step change
Additional Features 1: Ground Measurements
Additional Features 2: None
Insulation Resistance: 100 MΩ
Electrical Output Note: None
Process Connection Size: 9/16 in
Process Connection Type: UNF Female
Electrical Connection Note: Integral lightning surge protection to IEC-61000-4-5 (Level 4)
Thermal Effect on Span error, Max: ± 0.3% span
Thermal Effect on Zero error, Max: ± 0.3% span , ± 0.3% span
