Weight: 127 g
Accuracy: ± 0.5 %
Mounting: DIN rail types EN50022, 35 and 45
Stability: ± 0.5%
Hysteresis: ± 0.02%
Warm Up Time: 5 sec
Accuracy Note: ± 0.5% FS
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 25 inH₂O
Pressure, Min: -25 inH₂O
Response Time: 250 ms
Accuracy Class: > 0.25%
Burst Pressure: 25 psi Maximum
Proof Pressure: Up to 15 psi
Stability Note: Maximum change (full scale/ year) ± 0.5%
Supply Voltage: 12 to 36 Vdc
Linearity Error: ± 0.4% FS
Position Effect: 0.5" WC and higher 0.1% FS/g Below 0.5" WC 0.25% FS/g
Electrical Output: 4 to 20 mA
Enclosure Material: Glass-filled polycarbonate
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Repeatability Error: ± 0.05%
Line/Static Pressure: 25 psi
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Storage Temperature, Max: 82 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 82 °C
Operating Temperature, Min: -28 °C
Compensated Temperature, Max: 57 °C
Compensated Temperature, Min: 2 °C
Thermal Effect on Zero error, Max: ± 0.036% full scale/°C , ± 3% FS
