Weight: 14 g
Accuracy: ± 1 %
Sensitivity: 2 mV/V nominal
Accuracy Note: ± 1% FS (linearity and hysteresis combined)
Output Signal: Millivolt
Pressure Type: Gauge
Pressure, Max: 1000 psi
Pressure, Min: 0 psi
Accuracy Class: > 0.25%
Burst Pressure: 4x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 5 Vdc
Input Resistance: 350 Ω
Electrical Output: 2 mV/V
Materials, Wetted: FKM
Output Resistance: 350 Ω
Supply Power Note: 5 Vdc @15 mA
Enclosure Material: 17-4 PH Stainless Steel
Sensitivity Effect: ± 0.036% reading/°C
Zero/Balance Error: ± 3% FS
Burst Pressure Note: 400% range
Repeatability Error: ± 0.1% FS
Additional Features 1: None
Electrical Connection: Cable
Insulation Resistance: 5 MΩ @ 75 Vdc
Process Connection Size: 3/8 in
Process Connection Type: Flush diaphragm
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -54 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
