Accuracy: ± 0.25 %
Accuracy Note: 0.25% FS linearity and hysteresis combined
Output Signal: Digital
Pressure Type: Absolute
Pressure, Max: 1000 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 150% Full Scale
Trim Pot Access: O-ring sealed screws on side cover
Electrical Output: 4 to 20 mA
Materials, Wetted: 17-4 Stainless Steel
Electrical Connection: Cable
Insulation Resistance: 100 MΩ @ 50 Vdc
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 104 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Span Setting Adjustable Range: ± 10% FS
Zero Setting Adjustable Range: ± 10% FS
Thermal Effect on Zero error, Max: 0.003% of rdg/°F ,
