Length: 2.9 in
Accuracy: ± 0.25 %
Diameter: 1.25 in
Accuracy Note: 0.25% linearity, hysteresis and repeatability combined
Output Signal: Millivolt
Pressure Type: Gauge
Pressure, Max: 1000 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 2x Full Scale
Supply Voltage: 10 Vac/Vdc
Input Resistance: 360 Ω
Mating Connector: MIL-26482-I 10-6S
Electrical Output: 3 mV/V
Materials, Wetted: 17-4 Stainless Steel
Output Resistance: 350 ± 5 Ω
Supply Power Note: 10 Vac/dc (15V maximum)
Zero/Balance Error: ± 2.0% FSO
Burst Pressure Note: 300% of rated pressure
Proof Pressure Note: 200% of rated pressure
Electrical Connection: MIL-26482-I 10-6P
Electrical Output Note: 3 mV/V ± 2%
Process Connection Note: 1⁄8-27 NPT internal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 168 °C
Operating Temperature, Min: -54 °C
Compensated Temperature, Max: 168 °C
Compensated Temperature, Min: -40 °C
Thermal Effect on Span error, Max: 0.008% rdg/°F
Thermal Effect on Zero error, Max: 0.008% rdg/°F, 0.008% FSO/°F
