Weight: 3 kg
Accuracy: ± 0.075 %
Stability: ± 0.2%
Fill Fluid: Silicon oil
Damping Time: 0 to 100 sec
Power Supply: 500 mW
Accuracy Note: Accuracy (NLHR, 20°C ± 5°C): ± 0.075TD% SPAN (Square root output accuracy is 1.5 times linear output accuracy)
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 160 inH₂O
Pressure, Min: -160 inH₂O
Response Time: 200 ms
Accuracy Class: < 0.1%
Stability Note: ± 0.2% 60 months
Supply Voltage: 10.5 to 55 Vdc
Position Effect: Install error less than 400Pa (1.60” H2O) can be corrected by PV = 0 reset
Vibration Effect: GB/T 1827.3/IEC61298-3 tests, 20g (5 to 2000 HZ, max <± 3 mm), <0.1% URL
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67
Materials, Wetted: 316 Stainless Steel, FKM
Enclosure Material: 316L Stainless Steel
Media Compatibility: Air, Alkaline solutions, Any, Argon, Carbon dioxide, Dilute Acids, Gases, Helium, Hydraulic Oil, Hydrogen, Light Oil, Liquids, Nitrogen, Non-corrosive Dry Gasses, Oil, Oxygen, Solvents, Steam, Water, Water-based fluids
Loop Resistance, Max: <(U-10.5)/0.021Ω, where U is supply voltage
Additional Features 1: Rangable with 5 digit display
Electrical Connection: M12 4 pin
Transmission Distance: up to 1000 meters
Electrical Output Note: 4 to 20mA Two wire, linear or square root output selectable
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 120 °C
Process Temperature, Min: -40 °C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
Thermal Effect on Span error, Max: ± 1% absolute
Thermal Effect on Zero error, Max: ± (0.1 +0.1TD)% SPAN
