Accuracy: ± 0.75 %
Hysteresis: 0.15% FS (0.30% FS ≤5 psi range)
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 30 psi
Pressure, Min: 0 psi
Response Time: 1 ms
Accuracy Class: > 0.25%
Burst Pressure: 3x Full Scale
Supply Voltage: 8 Vdc
Linearity Error: ± 0.75%
Electrical Output: 1 to 6 V
Zero/Balance Error: 1.0 Vdc ± 0.05
Media Compatibility: Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Additional Features 1: None
Electrical Connection: Pins
Electrical Output Note: 1 to 6 Vdc (± 2.5 Vdc PX143)
Process Connection Size: 5 mm
Process Connection Type: Stem
Zero/Balance Error Note: 1 Vdc ± 0.05 (3.5 ± 0.05 Vdc PX163 Series)
Compensated Temperature, Max: 63 °C
Compensated Temperature, Min: -18 °C
Thermal Effect on Span error, Max: 0.01% FS/°F
