Accuracy: ± 1 %
Accuracy Note: ± 1% linearity, hysteresis and repeatability combined
Output Signal: Current
Pressure Type: Absolute
Pressure, Max: 25 psi
Pressure, Min: 0 psi
Accuracy Class: > 0.25%
Burst Pressure: 5x Full Scale
Proof Pressure: 2x Full Scale
Supply Voltage: 10 to 30 Vdc
Mating Connector: MIL-26482-I 10-6S
Electrical Output: 4 to 20 mA
Materials, Wetted: 316 Stainless Steel
Zero/Balance Error: 4 mA ± 0.2 mA
Burst Pressure Note: 500% of rated pressure
Proof Pressure Note: 200% of rated pressure
Electrical Connection: Cable
electrical-connection: Cable
Process Connection Type: Flush diaphragm
Operating Temperature, Max: 82 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 54 °C
Compensated Temperature, Min: -1 °C
Thermal Effect on Span error, Max: <± 2%
Thermal Effect on Zero error, Max: <± 2%, <± 1%
