Weight: 388 g
Accuracy: ± 0.09 %
Hysteresis: 0.05% FSO
Output Signal: Voltage
Pressure Type: Gauge
Pressure, Max: 500 psi
Pressure, Min: 0 bar
Accuracy Class: < 0.1%
Burst Pressure: 3x Full Scale
Linearity Note: 0.05% FSO
Proof Pressure: 150% Full Scale
Supply Voltage: 24 to 32 Vdc
Linearity Error: 0.0005
Sensing Element: 4-active-arm Strain Gauge Bridge
Mating Connector: MIL-26482-I 10-6S
Electrical Output: 0 to 10 V
Materials, Wetted: 17-4 Stainless Steel
Zero/Balance Error: 0 V ± 10% ADJ
Burst Pressure Note: 300% of rated pressure
Proof Pressure Note: 150% of rated pressure
Repeatability Error: ± 0.05% FSO
Sensing Element Note: 4-active-arm bridge, using thick-film strain gages in a hermetically sealed chamber
Additional Features 1: None
Electrical Connection: MIL-26482-I 10-6P
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Shunt Calibration Value: Value Specified on calibration sheet
Electrical Connection Note: PTIH-10-6P connector (or equal) Mating connector (sold separately), order PT06F10-6S
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -46 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Thermal Effect on Span error, Max: ± 0.002% FSO/°F
Thermal Effect on Zero error, Max: ± 0.002% FSO/°F, ± 0.001% FSO/°F
