Shock: Setpoint repeats after 75 g, 10 ms duration
Height: 4.88 in
Switch: Single
Weight: 12 oz
Deadband: 100 to 500 psi
Diameter: 1.25 in
Approvals: UL listed, cUL certified; Class I, Groups A, B, C, and D; Class II, Groups E, F, and G; Class III
Materials: 316 Stainless Steel, Stainless Steel
Vibration: Setpoint repeats after 15 g, 10 to 2000 Hz
Output Note: 5 A @ 250 Vac,5 A Resistive and 3 A Inductive @ 28 Vdc; Silver Contacts
Sensor Type: Diaphragm
Switch Note: Switch Output: 1 or 2 SPDT, factory sealed lead wires; mechanical contact life: 10 million cycles
Switch Type: SPDT NO/NC, Selectable
Output Value: 5A @ 250 Vac
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 3200 psi
Pressure, Min: 1000 psi
Repeatability: ± 1%
Control Output: SPDT Relay
Proof Pressure: Up to 10000 psi
Enclosure Ratings: IP66, NEMA Type 4X, NEMA Type 7, NEMA Type 9
Repeatability Note: ± 1% of adjustable range
Additional Features 1: FKM O-Ring
Electrical Connection: 1/2 NPT male Conduit with Wire Leads
Wiring/Connector Table: Red - N/C, Blue - N/O, Brown - Common, Green - Ground
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 160 °C
Process Temperature, Min: -17 °C
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -50 °C
Operating Temperature Note: -50 to 80°C (-58 to 176°F); setpoint typically shifts less than 1% of range for a 28°C (50°F) ambient temperature change.
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -50 °C
