Weight: 0.95 lb
Deadband: 200 to 500 psi
Diameter: 1.5 in
Materials: Plastic
Sensor Type: Sealed Piston
Switch Type: SPST
Deadband Type: Fixed
Pressure Type: Gauge
Repeatability: ± 1.5%
Switch Rating: 5 A maximum @ 125/250 Vac, silver serrated contacts 3 A max @ 28 Vdc
Burst Pressure: 14,000 psi Maximum
Control Output: SPST Relay
Proof Pressure: Up to 7000 psi
Thermal Effects: <1% for 25°C (45°F) change
Materials, Wetted: Brass, Buna-N (NBR), Stainless Steel
Repeatability Note: ± 1.5 of span
Electrical Connection: 1/2 NPT female Conduit with Wire Leads
Wiring/Connector Table: Red - N/C, Blue - N/O, Purple - Common
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Decreasing Pressure, Max: 3900 psi
Decreasing Pressure, Min: 1450 psi
Increasing Pressure, Max: 4400 psi
Increasing Pressure, Min: 1650 psi
Process Temperature, Max: 75 °C
Process Temperature, Min: -40 °C
