Width: 2.375 in
Height: 3.625 in
Switch: Single
Weight: 7.4 oz
Cycling: < 60 cycles/min
Deadband: 5 to 30 psi
Diameter: 1.625 in
Approvals: UL listed
Materials: Aluminum, Zinc Alloy
Sensor Type: Diaphragm
Switch Type: SPDT NO/NC, Selectable
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 150 psi
Pressure, Min: 30 psi
Control Output: SPDT Relay
Proof Pressure: Up to 600 psi
Materials, Wetted: Aluminum, Buna-N (NBR), Methacrylate Ester, Zinc-Aluminum Alloy with Chromate Finish
Electrical Connection: Screw Terminal
Setpoint Repeatability: ± 5.0 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature Note: -35 to 85°C (-31 to 185°F); 2% setpoint shift can occur below -23°C (-10°F) or above 52°C (125°F)
Process Temperature, Max: 85 °C
Process Temperature, Min: -35 °C
