Switch: Dual
Deadband: 2.5 to 5.9 inH2O
Materials: 316 Stainless Steel, PTFE, Stainless Steel
Output Note: 15 A: 125/250/480 Vac, 0.5 A: 125 Vdc, 0.25 A: 250 Vdc
Sensor Type: Diaphragm
Switch Note: Two SPDT switches can be wired “normally open” or “normally closed”
Switch Type: SPDT NO/NC, Selectable
Output Value: 15A @ 125/250/480 Vac
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 3000 psi
Pressure, Min: 450 psi
Control Output: SPDT Relay
Proof Pressure: Up to 12000 psi
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: PTFE, Stainless Steel
Electrical Connection: 3/4 in NPSM with Screw Terminal block
Setpoint Repeatability: ± 1%
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Storage Temperature, Max: 66 °C
Storage Temperature, Min: -29 °C
Operating Temperature, Max: 66 °C
Operating Temperature, Min: -29 °C
Setpoint Repeatability Note: Typically shifts ± 1% of range per 28°C (50°F)
