Width: 4.125 in
Height: 6 in
Switch: Dual
Weight: 2 lb
Deadband: 1.4 to 2.8 psi
Diameter: 3.75 in
Approvals: UL listed, CSA certified
Materials: Aluminum, NBR, Nitrile Rubber
Output Note: 10 A 125/250 Vac, 0.5 A: 125 Vdc, 0.25 A: 250 Vdc, 15 A: 125/250 Vac
Sensor Type: Diaphragm
Switch Note: 1 or 2 SPDT switches can be wired "normally open" or "normally closed"
Switch Type: SPDT NO/NC, Selectable
Output Value: 15A @ 125/250 Vac
Deadband Type: Fixed
Pressure Type: Differential
Pressure, Max: 60 psi
Pressure, Min: 9 psi
Control Output: SPDT Relay
Proof Pressure: Up to 2000 psi
Enclosure Ratings: IP66, NEMA Type 4X
Electrical Connection: 3/4 in NPT female Conduit with Screw Terminal block
Setpoint Repeatability: ± 1%
Process Connection Note: 1/4 FNPT; brass-plated carbon steel for psid ranges; carbon steel for H2O ranges; 1/2 NPT male for vacuum to 600 psi; 1/4 FNPT for 1000 and 3000 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Storage Temperature, Max: 66 °C
Storage Temperature, Min: -29 °C
Operating Temperature Note: -29 to 66°C (-20 to 150°F); setpoint typically shifts +1% of range per 28°C (50°F) of temperature change.
Operating Temperature, Max: 66 °C
Operating Temperature, Min: -29 °C
