Shock: Setpoint repeats after 15 g, 10 ms duration
Width: 4 in
Height: 8.4 in
Length: 2.3 in
Switch: Single
Weight: 6 lb
Deadband: 3.6 to 3.6 inH2O
Approvals: UL listed
Materials: Stainless Steel, Aluminum, Epoxy, NBR, Nitrile Rubber
Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz
Output Note: 11 A 125/250 Vac resistive
Sensor Type: Diaphragm
Switch Note: Switch Output: Hermetically sealed SPDT or DPDT switch can be wired “normally open” or “normally closed”
Switch Type: DPDT
Weight Note: 0.7 to 2.7 kg (1.5 to 6 lb) (varies by model)
Output Value: 11A @ 125/250/480 Vac
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 1700 psi
Pressure, Min: 100 psi
Control Output: DPDT Relay
Proof Pressure: Up to 2500 psi
Enclosure Ratings: IP66, NEMA Type 4X
Electrical Connection: Screw Terminal
Setpoint Repeatability: ± 1%
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 93 °C
Process Temperature, Min: -23 °C
Storage Temperature, Max: 71 °C
Storage Temperature, Min: -54 °C
Operating Temperature Note: setpoint typically shifts less than 1% of range for a 28°C (50°F) ambient temperature change
Operating Temperature, Max: 71 °C
Operating Temperature, Min: -18 °C
