Shock: Setpoint repeats after 15 g, 10 ms duration
Width: 4 in
Height: 7.5 in
Length: 2.3 in
Switch: Single
Weight: 2 lb
Deadband: 1 to 2 inHg
Approvals: UL listed
Materials: Aluminum, Epoxy, Bronze, NBR, Nitrile Rubber
Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz
Output Note: Standard 15 A 125/250/480 Vac resistive
Sensor Type: Bellows
Switch Note: One SPDT or DPDT switch can be wired “normally open” or “normally closed”
Switch Type: SPDT NO/NC, Selectable
Output Value: 15A @ 125/250/480 Vac
Deadband Type: Fixed
Pressure Type: Compound Gauge
Pressure, Max: 0 psi
Pressure, Min: -15 psi
Repeatability: ± 1%
Control Output: SPDT Relay
Proof Pressure: Up to Ambient Pressure
Enclosure Ratings: IP66, NEMA Type 4X
Electrical Connection: Screw Terminal
Setpoint Repeatability: ± 1%
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 150 °C
Process Temperature, Min: -40 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -55 °C
Operating Temperature Note: -40 to 70°C (-40 to 158°F), except models PSW-107 to PSW-117 and PSW-134 to PSW-139: -20 to 70°C (-4 to 158°F); setpoint typically shifts less than 1% of range for a 30°C (54°F) ambient temperature change
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -40 °C
