Accuracy: Class A
RTD Type: 100 Ω Pt Sensor
Output Note: IO-Link Communication / PNP Switch (200 mA) / Analog 4-20 mA
Probe Length: 4 in
probe-length: 4 in
Accuracy Note: Full Measuring Range ± 0.55 °C (0.99°F) Scaled Measuring Range ± [0.215 °C (0.39 °F) + 0.134 % x (Measuring Span)]
Response Time: 2 sec
Certifications: CE, UKCA
Data Interface: IO-Link
Probe Diameter: 0.125 in
Sheath Material: 316L Stainless Steel
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67, IP68, IP69K
Thermocouple Type: N/A
Enclosure Ratings Note: 316L Stainless Steel, IP67/IP68/IP69K rated
Operating Voltage Note: 15 to 30 VDC (IO-Link/Switch); 10 to 30 VDC (Analog)
Operating Voltage, Max: 30 VDC
Operating Voltage, Min: 15 VDC
Priint status (variant): Start PDF generation
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Temperature Sensor Type: RTD
Process Temperature, Max: 200 °C
Process Temperature, Min: -50 °C
Priint template (variant): [{"code":"dwyer_poc_template","values":{"label":[{"locale":"en_US","channel":null,"data":"Dwyer-POC-Template"}],"image":[{"locale":null,"channel":null,"data":"b/c/a/6/bca6631885dfdc64785b40961ecd80b9d0e9af8c_Omega_Logo.png"}],"priint_pdf_field":[{"locale":null,"channel":null,"data":"priint_pdf"}],"priint_pagetemplate_identifier":[{"locale":null,"channel":null,"data":"1"}],"priint_template_identifier":[{"locale":null,"channel":null,"data":"67765085"}],"priint_masterdocument_identifier":[{"locale":null,"channel":null,"data":"DWYER-OMEGA_SINGLE-SKU_TEMPLATE"}]},"created":"2025-01-31T18:58:27+00:00","updated":"2025-01-31T21:49:11+00:00"}]
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
