Width: 1.38 in
Height: 3.88 in
Weight: 0.35 lb
Diameter: 1.38 in
Mounting: Pipe, panel, through body, bracket
Materials: Aluminum,Chromate,Epoxy,Nitrile Rubber,Steel,Brass,Stainless Steel
Sensitivity: 0.25 inH2O
Pressure Type: Gauge
Repeatability: 0.3% of span
Flow Rate Note: 10 SCFM @ 100 psi inlet
Media Compatibility: Air
Output Pressure, Max: 120 psi
Output Pressure, Min: 0 psi
Supply Pressure, Max: 150 psi
Exhaust Capacity, Max: 7 SCFM
Total Air Consumption: 6 SCFM
Process Connection Size: 1/16 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 10 SCFM
Operating Temperature, Max: 71 °C
Operating Temperature, Min: -18 °C
Total Air Consumption Note: 6 SCFH maximum at 150 psi supply
Supply Pressure Sensitivity: 0.6 psi
