Weight: 272 g
Display: YES
Accuracy: ± 2 %, ± 5% with transitional flow
Cable Length: 6 ft
Display Size: 47 mm (1.9 in)
Laser Output: false
Air Flow rate: 1 CFM
Field of view: 6:1
Housing Width: 65.5 mm
Output Detail: 0 to 10V; Open drain, 100 mA
Output Signal: Voltage
Repeatability: ± 1%
Response Time: 100 ms
Sensor Length: 63.5 mm
Thermal shock: About 30 minutes for 25°C (77°F) abrupt ambient
Alarm Deadband: 5.5°C (10°F)
Alarm Setpoint: Adjustable, 0 to 100%
Control Output: Open drain
Data Interface: RS232
Housing Height: 30.5 mm
Housing Length: 115.3 mm
Supply Voltage: 12 to 24 Vdc
Emissivity Note: 0.1 to 1.00, adjustable
Emissivity, Max: 1
Emissivity, Min: 0.1
Sensor Diameter: 25.4 mm
Water Flow Rate: 0.25 GPM
Housing Material: Aluminum
Electrical Output: 0 to 10 V
Enclosure Ratings: IP65, NEMA Type 4
Field of View Note: 6:1 (distance/ spot size)
Response Time Note: 119 ms (0 to 63% of final value)
Data Interface Note: Serial RS232, 2-way
Warm-Up Period, Max: 3 m
Warm-Up Period, Min: 0 m
Water Flow Rate Note: 0.25 GPM, room temperature
Relative Humidity Note: Less than 95% RH, non-condensing
Relative Humidity, Max: 0.95
Spectral Response, Max: 14 μm
Spectral Response, Min: 5 μm
Process Temperature, Max: 538 °C
Process Temperature, Min: -18 °C
Temperature sensing Head: High
Operating Temperature, Max: 85 °C
Operating Temperature, Min: 0 °C
