Shock: 50 g, 11 ms half sine, vertical and horizontal axis
Weight: 200 g
Accuracy: ± 0.2 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: 5-2000-5 Hz, 30 minute cycle, Curve L, Mil-Spec 810 figure 514-2-2, vertical and horizontal axis
Cable Length: 2 m
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 1 psi
Pressure, Min: 0 psi
Response Time: <1 ms
ADC Resolution: None
Burst Pressure: 1000 psi Maximum
Proof Pressure: 6x Full Scale up to 1000 psi
Stability Note: Long Term Stability (1-Year): ± 0.1% FS typical.
Supply Voltage: 9 to 30 Vdc
Pressure Cycles: 1 million, minimum
Trim Pot Access: O-ring sealed screws on side cover
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67
Materials, Wetted: 316L Stainless Steel
Supply Power Note: 9 to 30 Vdc [9 to 20 Vdc above 105°C (229°F)] max loop res Ω = (Vs-9) x 50
Media Compatibility: Air, Alkaline solutions, Any, Argon, Carbon dioxide, Dilute Acids, Gases, Helium, Hydraulic Oil, Hydrogen, Light Oil, Liquids, Nitrogen, Non-corrosive Dry Gasses, Oil, Oxygen, Solvents, Steam, Water, Water-based fluids
Proof Pressure Note: Positive Side
Line/Static Pressure: 500 psi max applied to both sides simultaneously
Electrical Connection: 1/2 NPT male Conduit with Cable
Insulation Resistance: 100 MΩ @ 50 Vdc
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -45 °C
Compensated Temperature, Max: 93 °C
Compensated Temperature, Min: -18 °C
Span Setting Adjustable Range: ± 10% span
Zero Setting Adjustable Range: ± 10% span
Thermal Effect on Zero error, Max: ± 1% FS
Positive Side differential wetted materials: 316L stainless steel
Negative Side differentional compatable fluids or gasses: Same as positive side
